Hardwired Vehicle Tracker - 1 Year Service Included

The hardwired vehicle tracker requires a slightly more involved installation than our Plug and Play device. This device is more discrete and harder to tamper with.

You may wish to hire a car electronics shop to install this if you aren't comfortable with vehicle wiring.

The hardwired tracker can be placed somewhere discrete in your vehicle and provides live location data for your ride. The tracker is easy to wire, requiring at minimum only 12v power with a ground. You may also connect an accessory wire to report when the vehicle is on or off. The device comes with a wiring harness (not pictured).

This tracker comes with an included 1 year of online self tracking service from the date of purchase. Additional service can be added as desired.

Wiring Notes:
You will need to wire at minimum, power. The cable harness shipped with the device is color coded as follows:
Power 12v (accept 10-30v) - Red, Pin#1
Power Gnd - Black, Pin#7
Ignition/Accessory - Yellow, pin#5 (optional)

Optionally, you can wire yellow, "IGNITION DIN1" pin#5 to your vehicles accessory circuit. This will allow the service to report if the tracked asset is on or off.
The remaining wires in the harness are not used at this time.

Optional: This same tracking hardware can also be used for more advanced applications. Please contact us for a custom quote and to discuss options.
